Pollinators and Pesticides - A look at modern Neurotoxins

Pesticides and Pollinators - A look at Modern Neurotoxins (ppt file)- Slide presentation by Gary Rondeau prepared for 2014 SAVE the BEES event.  ppt file has comment for many slides that will aid in understanding the presentation.  PDF version does not have comments.

Honey in the making: a photo essay

June 8, 2013

june 13 062

Bees are working everywhere.  Please don’t spray!  Especially when a plant is blooming. And don’t use insidious granules or injections of “neonics” on trees that will continue to poison pollinators for years.

Did you know spraying a blooming honey plant is also against the law?  Help protect the pollinators that are necessary to the majority of human food crops– not to mention the health of our ecosystems.

spring 2013 053

Bee covered in dandelion pollen

spring 2013 014

         Bee busy on butterfly lavender: they love regular lavender too

bee on bluebell

Bee sipping nectar from a bluebell: note the pollen packet on her leg.

013

Continuing a partnership began over a hundred million years ago

Bees on mountain blue

nov 2012 016

nov 2012 013

Bee sipping from an English ivy bloom: photo taken in November when other nectar crops are sparse

bee on the way to pollinate clematis

OLYMPUS DIGITAL CAMERA

Bee heading for a clematis flower and working it

OLYMPUS DIGITAL CAMERA

OLYMPUS DIGITAL CAMERA

Bees on mint blooms: one of their favorites

native bee posing for the camera?

stuffing pollen baskete

             bee on fennel

Fennel is another favorite

3.8.13 009

Bee on rosemary: herb nectar helps keeps bees healthy

3.8.13 011

Love that rosemary!

016

022a

Bee on boxwood:  bees work tiny closed buds to get them to open.  Bees will encourage blossoms of other plants to bloom in the same way.

016a

027

028

When the blackberry bloom is on in May and early June, the honey flow is abundant.

spring 2013 018

spring 2013 017

Lunara blooms in early spring to bring in the bees

spring 2013 026

spring 2013 028

And bees don’t forget the forget-me-nots

These photos represent only a very small portion of the diversity of honey plants utilized by bees. For instance, there are our fruit and nut trees.   I didn’t get any pictures of bees working twenty or thirty feet in the air, but my burgeoning backyard fruit crop indicates their presence. There are also our ornamentals:  such as linden, locust, maple and poplar utliized for nectar, pollen, and propolis (the bee “antibiotic”).  They will also work single-petaled roses such as Nootka and Darwin’s Enigma and join native pollinators on mock orange and ceanothus.  Bees could compose their own plant encyclopedia– likely far more extensive than the ones humans put together!

june 13 062

We can’t say it too often!  Don’t poison bees that do so much for us–and don’t poison other wildlife, pets and children along with them!

These photos are protected by copyright (Madronna Holden 2013).  But feel free to link here or to use these photos with credit in any way that supports our pollinator populations.

Advertisement

Will Jerry’s Stop Selling Neonics? With your Help!

June 6, 2013

Our group has bee attempting to get retailers in our community to stop selling the worst neonicotinoid insecticides.  Probably the largest retailer of these products in Lane county is Jerry’s Home Improvement Centers, with two large and popular stores in Eugene and Springfield.  Our estimates, from observed store traffic, number of retailers in the county, and shelf-space devoted to the chemicals is that Jerry’s is responsible for at least a third of these chemicals sold in the Eugene-Springfield area.

Jerry’s is a local, employee-owned company, so we felt that they could be approached and would be responsive to an issue which effects their customers, employees, friends and neighbors.  Philip, in our group, established a convivial relationship with the Jerry’s garden center manger, Jeffery Choat, and we were eventually given VP of operations Scott Lindstrom as our point contact at Jerry’s for this issue.

Below you can see the e-mail dialog that we had with Jerry’s about this issue.  Unfortunately, The Jerry’s management decided not to take any constructive action, despite our efforts to find common ground.  It has been several months now, with no movement from Jerry’s.  However the world has become even more aware of the problem and people everywhere are voicing their concern.  In May the European Union instituted a ban on products we would like to see Jerry’s stop selling for all of Europe.  Locally, the word is getting out that these chemicals are a problem.  Last week’s march against Monsanto had a large contingent of beekeepers and concerned citizens demonstrating against the use of neonicotinoid insecticides.

Our online petition is close to the 500 signature mark, and we have gathered hundreds more signatures the old fashioned way.  With such strong community support we expect that local companies will soon not be able to ignore their customers and will have to listen to us.  Thanks to all that have signed our petition, and stay tuned for the fun to come.  We need everyone to help stop the tide of chemicals flowing into the community from local retailers, poisoning all manner of beneficial insects and bees.

What follows is the e-mail dialog with links to the materials we presented to Jerry’s.

2/26/2013

Dear Mr. Rondeau,

I am writing in response to your concerns related to neonicotinoid.  I am your contact and will look into this matter. Please forward me any credible information from reliable sources including EPA, university or independent studies confirming your concerns.  Our company has made no decision with respect to these chemicals at this time, but look forward to receiving valid scientific data on the issue.

I have gone to your web site and noticed you have taken a photo of our store.  I am asking you respectfully to remove our name (as shown on the pricing labels) down from your web site.  With three major retailers in our area selling these exact chemicals (Home Depot, Lowe’s, Wal-Mart), and two large regional chains(Bi Mart and Fred Meyer) selling these exact chemicals in our geographic area,  I feel you are unjustly targeting us.

Regards,
Scott Lindstrom
VP Operations
Jerry’s Home Improvement

2/26/2013

Hi Scott,

Sorry you don’t appreciate my photo 🙂  I was careful NOT to single out Jerry’s when I identified it as a “local garden center” because it is not just you, as you point out.  If I go though the trouble of blocking out your name on all of the price labels, it will probably just draw attention to where the picture was taken by those curious to know.  But if you wish, I will do so.

In the mean time let me start to send you a rather large compendium of scientific and policy papers on this issue.  The scientific papers are from various journels published over the last decade or so. The policy statements are mostly involving the European process now taking place.  The EPA is behind in this.  I am also in touch with Oregon Dept. Agriculture people on this issue, and may have info from them as well.  The issue beekeepers are facing is that the EPA has been slow to react and the  devastation to honey bee colonies and native pollinator continues.  Hence, our emphasis is now to look to where the policy debate HAS been moving forward, Europe, and to try to use that example to influence both private companies, such as Jerry’s and our state officials.

A good place to start is:  December 2012, the European Parliament issued a report, Existing Scientific Evidence of the Effects of Neonicotinoid Pesticides on Bees also attached as a PDF.  This is a shorter summary of the much larger EFSA report.  It references many scientific papers.  I am still going over all of this material my self, but I can point to a couple of things that I find worthy of consideration.  Please look over section 6 of the above report.  The issue of how we even think about low doses of extremely toxic chemicals is addressed, especially regards scientific articles by Tennekes, et.al.  Attached is the one article I’ve had time to get to, but I found its implications profoundly troubling.

I also attached a paper that makes the connection between low levels of neonics and disease susceptibility.  This is just one example of many, but lets start here.  I can send you much more, but I would rather tailor the paper toward punch and not bulk.  I can’t read it all in one sitting either!

I look forward to your comments.

Best regards,
Gary

Attachments:

Existing Scientific Evidence of the Effects of Neonicotinoid Pesticides on Bees

Time-Dependent Toxicity of Neonicotinoids and Other Toxicants:
Implications for a New Approach to Risk Assessment

Pesticide exposure in honey bees results in increased
levels of the gut pathogen Nosema

2/28/2013
Dear Mr. Rondeau,

Thank you for graying out our logo from the photo on your web site.  Our expert here at Jerry’s is in the process of reviewing the documents both you and Mr. Smith sent.  We have been in contact with the ODA, our contact at UC, Davis, and Oregon State University.  Once our research is complete, I will send you our conclusions and decision.

Regards,
 Scott Lindstrom
 VP Operations
Jerry’s Home Improvement

2/28/2013
Hi Scott,
I’d actually like to “make the case” in a more formal written form.  This will take me longer than I have right now, but I will be sending you a little more stuff in the near future.  We really appreciate your thoughtful consideration of this matter.Thanks,
Gary
3/2/2013
Dear Scott,

I’ve run across a few materials that provide a more succinct view of pertainant information aimed for a non-expert audience.  The first item is a power point presentation by a graduate student in Dr. Vera Krischik’s lab at the University of Minnesota.  Dr. Krichik made headlines last year when she reported that residential application of insecticides frequently resulted that much higher levels of residual chemical in pollen and nectar than is acceptable, or occurs in agricultural crops where applicators are more knowledgeable and the chemical levels needed for specific crops are better codified. Unfortunately, Dr. Krischik’s work has not yet been published in journals.  The power point by one of her grad students, however, is good in that it includes a nice tabulation of levels of exposure that are problematic and some of the levels seen in pollen and nectar of treated plants.   It follows with the interesting experimental results with bumblebees.  This is a large file that failed to mail… please find it here:

Link to UM bumble bee PPT file

I also attach another article by Tennekes.  This is a review article that looks beyond just honeybees at the larger implications of these toxic chemicals.  He forcefully makes the case that the toxic effects of these chemicals extend beyond insects.

One problem I have had in attempting to better understand this issue is lack of good data on the amount of these chemicals actually being used, especially in homes, gardens and other suburban and urban applications (golf courses, parks, etc.)  The chemical manufacturer (Bayer most often in this case) has trade marked or named consumer products that they supply for a particular use.  For example, “Bayer Rose and Flower Care,” contains imidicloprid now, but has in always?  Was there a Bayer Rose care product before imidocloprid was introduce (1996)?  What is the sales pattern for these chemicals for residential uses over the years?
I’m wondering if you have sales information on these products you would be willing to share?  Obviously Jerry’s is just one outlet, but any information is better than none, when it comes to what is happening locally.
My own observation is that the problems with crashing bee colonies in the suburban/urban areas around here have gotten significantly worse in the last couple of years.  CCD hit the news in ~2006 for beekeepers with colonies placed on agricultural crops.  The last couple of years we have had more problems locally.  So one question I have is, when did this stuff really hit the market here?  Any answer – since you folks sell it?

Best regards,
Gary

Attachment:


3/2/2013
Dear Mr. Rondeau,

Attached you will find our summary.  There is no clear cause of Colony Collapse Disorder (CCD).  Most of the research points to needing more research.

We believe we have a very pro environmental president with President Obama.  We feel if CCD is in fact linked to neonicotinoids, banning them would have the best chance under this administration. Banning them would even the playing field for all retailers selling this product.  We feel at this time we will continue selling this product until such time the EPA bans these chemicals.

Regards,
Scott Lindstrom
VP Operations
Jerry’s Home Improvement

Attachment:

Jerry’s findings on Neonicotinoids

3/10/13
Dear Scott,

Needless to say, I’m disappointed by your decision.  The reason why our group approached Jerry’s with our request is that your company is locally owned and operated.  Your owners, employees and their friends and neighbors live with the chemicals you sell, so you have reason not to foul your own nest.  In this country we rely on the EPA to protect us from harmful chemicals and pesticides.  To a large extent they do a good job, but they are not infallible and are subject to pressure from a spectrum of special interests.  As your decision illustrates, it is much easier to do nothing than to rock the boat.  Human nature is to defend a bad decision to the end rather than change one’s mind.  The EPA and its leadership are in this position, making a rational assessment of the risks less likely.  With these insecticides already on the market, adding restrictions at this time is a much harder decision than was the permitting process in the first place.

The EU process illustrates what is required:  first, a careful look at the scientific evidence, and then the application of the precautionary principle.  As you point out in your survey of the current state of our knowledge, the issue of blame for the neonics is far from clear, and there is an almost universal call for more research to get to the bottom of the issue.  I think we agree on the facts.  The real question is whether to apply the precautionary principle or not.  This is where we have to look to our community values.  The EU tends to be more concerned about environmental effects than we do in the US.  For example GMO’s are much more severely restricted in the EU.  Our community is a little northwest of normal compared to the rest of the US.  We seem to enjoy “process” here, be it over highway projects or backyard chickens and bees.  We value our natural spaces, our forest lands, our gardens.  We are not wont to inadvertently destroy them with toxic chemicals and we are generally willing to apply the precautionary principle.  This really is the heart of our request, and is in keeping with our local community values.

I would like to stress that there is a spectrum of actions that Jerry’s could take short of removing all neonicotinoid insecticides from the shelves that would be helpful.  For example, just removing products containing imidacloprid would significantly reduce the worst toxic substance the bees are exposed to in our community.   Recognizing the difference in toxicity between imidacloprid and acetamiprid is reasonable, and would allow keeping quite a number of Ortho products on the shelf and provide customers who feel they need chemicals with an effective insecticide while reducing the use of the more long-lived and more toxic imidacloprid.

Other actions Jerry’s could take that fall short of voluntarily removing the problematic chemicals would be just to not actively promote them.  Reduce shelf space devoted to the imidicloprid products.  Instruct staff about the alternatives and promote safer products.  Remove impulse-buy displays located in high-traffic store locations.  Compared to other big-box stores in the area Jerry’s devotes more display space to these chemicals than any other retailer.

Finally, help us to understand the problem better.  Jerry’s is one of the bigger retailers of these products in the area.  Sales history of products containing imidacloprid could help us understand how much recent bee colony losses in the urban community are related to insecticide use or NOT.

We are not asking Jerry’s to be the most environmentally friendly store in our community, but we certainly hope you won’t be among the worst.  Jerry’s business relies on good community relationships.  Many of us choose to shop at Jerry’s because we value our local employee-owned company over national big box chains.  The flip-side, however, is that Jerry’s needs to be attuned to our community values or there is little reason for our loyalty.

I certainly hope that there is still progress to be made on this issue, and would welcome a meeting in person if that would be helpful.

Best regards,

Gary

Bees on honey plants

June 1, 2013
Bee covered in dandelion pollen

Bee covered in dandelion pollen

spring 2013 024

Bee obtaining nectar from a forget me not.

bee on mountain blue

bee on mountain blue

bee working butterfly lavendar

bee working butterfly lavendar

bee on bluebell

Bee drinking nectar after packing pollen from a bluebell

Blackberry bloom is on: please don’t spray now

June 1, 2013

As Oregon beekeepers know, blackberry blossoms are a major crop worked by bees.  I (Madronna) was therefore distressed to find that someone saturated a blackberry-covered hillside in my neighborhood with herbicide yesterday (May 31).

Spraying any pesticide on this plant at this time will poison honeybees and native pollinators both.

This is a plea to all h0meowners to honor the Oregon Department of Agriculture guidelines NOT to spray crops worked by bees while the bloom is on them.

Thanks for helping to keep our honeybees vibrant.

Time-dependent Toxicity of Imidacloprid in Bees and Ants

May 12, 2013

Honeybee colony losses continue to be unacceptably high.  In the US this spring, colonies brought in to California to pollinate almonds from throughout the country, about half of the colonies were lost (New York Times, March 29, 2013).  It is generally accepted that multiple pathogens ultimately bring down stressed colonies (Cornman 2012).  However the role of pesticide stress on colonies remains controversial.  Chronic exposure studies are often poorly constructed and frequently do not follow the exposed insects long enough for effects of the toxin to become evident.  The best studies look at mortality, or behavioral effects, over a substantial fraction of the insect’s lifespan while varying the toxin concentration or dose.  Time-to-effect studies lend themselves to a simple time dependent “power law” empirical model which can guide expectations for field toxicity effects (Tennekes 2011, Sánchez-Bayo 2009).  Other reviews of the toxicity of imidacloprid (Cresswell 2011) attempt to establish specific “acute” or “chronic” levels, but this seems useless if the time of exposure is not explicitly included.

Hence, I’ve made an effort to identify relevant time-to-effect studies in the literature  most specifically for imidacloprid with insects of order hymenoptera, which includes bees and ants.  As it turns out, there is an interest in concocting ant baits that proffer sub-lethal doses of toxin to forager ants.  A study done by Rust, et.al. 2004, has time-dependent toxicity measurements for imidacloprid on Argentine ants.

For the honeybee data, we have the paper by Suchail et.al. 2001 that I discussed previously. However, there is general concern in the research community that there is something wrong with the Suchail results.  Many other studies do not show such a  high sensitivity to the toxin.  So I looked for other experiments that also include time-to-effect measurements.  There is a study by DEFRA (2007) that has time-to-effect figures, and also a compilation to many researchers’ LD50 numbers for 24, 48, 72, and 96 hr. periods (FERA 2013).    To be able to plot both chronic and acute data on the same graph, I take the acute LD50 numbers and divide by the time interval for the measurement to obtain daily dose rates.Dechaume-Imidicloprid_chronic data  At higher concentrations there is an anti-feedant  effect that reduces the consumption rate, so I’ve plotted the reported consumption of toxin (ng/day) versus the time of exposure until half the bees have died (LT50).

Many studies only follow the bees for 10 days or less.  At lower concentrations, the LT50 time is never reached in the experiments.  However, there is a paper by Dechaume-Moncharmont, et al. 2003, which contains a couple of data points with time-to-effect numbers for relatively low sub-lethal concentrations.  The data show  that 4-8 ppb samples eventually kills bees in  about 30 days.   All of these data are plotted in the chart below.  I had to estimate the consumption rate for the ants in order to plot it with the other data, but an incorrect estimate would shift the curve left or right, but not change its slope.  I show the power law best-fit line for each data set, where the Dechaume-Moncharmont points (blue squares) are included with LD50 averages from the FERA 2013 paper.

Imidacloprid Time Dependent Toxicity for Bees and Ants

First notice that the LT50 times for the Argentine ants do a remarkably good job of following a simple power law with roughly t1.7 dependence.  This adds confidence to the utility of the empirical power law model for imidacloprid.  Recall that simple accumulation to a toxic threshold would appear as directly proportional to time ( t1.0 ). An exponent larger than one can be interpreted as coming from damaging secondary physiological effects that take time to develop.

The DEFRA data stands out as not falling with the averages of other researchers.  In general, there appears to be a wide variation between experiments, and hence individual colonies or strains of bees, to the sensitivity of this insecticide.  The DEFRA study has time-to-effect numbers and consumption data, so it provides a good data set for looking at time scaling, even if the DEFRA bees are not particularly representative of most other bees tested.  Again we see the data taken can be very well explained by the power law formulation, this time with about t1.6 dependence.  We might expect that healthy individuals of similar species would exhibit similar temporal effects to the same toxin, and this seems to be the case.  Finally, the average LD50 numbers from many researchers also fits the power law model.  I also included the Dechaume-Moncharmont data in the power law fit, here about t2 .  The Dechaume-Moncharmont data extends the  model into the high field-realistic exposure range when approaching the lifespan of summer bees.   If we extrapolate the curve to the lifespan of winter bees, we are well into the range of field-realistic exposure (0.01 ng/day).  Hence, even with healthy bees, exposure to modest field-realistic levels of imidacloprid will compromise the longevity of winter bees, and could easily cause problems getting the bees through the winter.

It is known that imidacloprid is relatively quickly metabolized in the honeybee.  The metabolic half-life is about 5 hours (Suchail 2004). Yet the effects of the poison are cumulative and long-lasting.  This seeming paradox is explained by the fact that when the imidacloprid molecule binds to the nAChR receptor sites in the nervous system of the insect, it binds strongly and essentially irreversibly.  So while free circulating imidacloprid may decay away, the damaging bound molecules remain, continuously compromising the nervous system.

The imidacloprid toxicity graph tells us that we need to be careful not to expose bees to more than a very few parts per billion (ppb) of toxin if we wish there to be no effect over the lifespan of the bees.  Reports of levels of neonicotinoids from treated agricultural crops are frequently in the 1 to 5 ppb range.  Typical honeybee consumption is about 20 µl/d, so at 5 ppb, the ingested toxin would be 0.1 ng/day which is the upper end of the yellow zone in the figure.

The Suchail (2001) results show a much higher sensitivity to imidacloprid than would fit the trends we see with the other data sets. Rather than the  t2  dependence, lethal effect seems to scale as toxic concentration times t5.  It is tempting to disregard the Suchail results, however one test site in trials by Shmuck (2004) also showed very high sensitivity to imidacloprid as well.  Hence it is worth considering a secondary stressors that could result in a higher sensitivity to the toxin.  The logical culprits would be pathogens, bacterial, viral or the microsporidian nosema.

Pathogen interactions with a host could lead to several time-dependent processes. First, damage to the host immune system has to occur for a pathogen to get a foothold. Then, before the host succumbs to the pathogen, the infectious organism must grow and multiply to lethal levels. Damage from the pathogen itself may take time to manifest in the host organism. Several of these time-dependent processes happening simultaneously would lead to a higher order time dependence.

The interaction between nosema and imidacloprid was studied by Alaux, et. al. (2010).  The study fed bees 200,000 nosema spores to initiate infection and subject the bees to various doses of imidacloprid.  There was some interaction between the pesticide and the pathogen, but the study only followed the bees for ten days so it is hard to draw conclusions at field-realistic doses, and the nosema infection dominated the experiment.  Two data points from the study are plotted on our graph (blue diamonds).

A very good study, Aufauvre (2012), looks at the interaction of the systemic insecticide fipronil and nosema infection, and finds a strong synergy between the pesticide and the pathogen.  The figure from that paper, below, shows what happens when sub lethal infection levels are combined with sub lethal insecticide exposure.

Aufauvre, et.al. 2012

The curves (purple) show what happens with both the pathogen and the toxin combined.  Neither nosema alone (red) nor fipronil alone (green) are very different from the control (blue), since  low doses were used.  However, the combination, given enough time, is especially lethal.  The study examines the effects of the relative timing of the exposure and infection, but finds synergistic interaction between the pathogen and the toxin in all cases.  The study followed the bees for twenty-two days, significantly longer than the typical ten-day chronic studies.  The added time is crucial for the delayed toxic and synergistic effects to show up.  The same is true with the Dechaume-Moncharmont experiment, where there were no deaths in either the control or exposed bees at the ten-day point, yet the toxic effect was clearly evident by day 30.

The choice of nosema as the pathogen for this study is convenient because the infection is easily accomplished with a spore solution, and the progress of the infection can be followed with microscopic examination of the bees.  Curiously, the level of the nosema infection as measured by spore counts,  was not much different with or without the pesticide exposure. Viruses are much more difficult to use as the infectious agent because of the difficulty of diagnosing their presence and quantifying the infectious dose and infection progress.  However, viruses are more ubiquitous in honeybee colonies than nosema, and could easily have a similar synergistic interaction with pesticides on the bee’s health.

Cornman et al. (2012) found that CCD (colony collapse disorder) colonies were more likely to have higher levels of a wide variety of pathogens than weak, but non-CCD, colonies.  Not only were the levels of pathogens higher, but multiple agents were frequently found in combinations not typical of non-CCD colonies.  The figure below from that paper does a great job of graphically illustrating the situation.

Pathogen Webs

It looks like the immune system has gone awry.  Could it be a few parts per billion of insecticide that makes the difference?  More research is still needed here, perhaps looking at pesticide interaction with KBV or AMPV virus, since these viruses show up in CCD colonies.

Extrapolating LD50 numbers or 10-day chronic LC50 values to the lifetime of bees wintering in the honeybee colony requires some understanding of the time-dependent nature of the toxin.  We have shown that the published LD50 and LC50 data can be empirically modeled using a simple power law.  For imidacloprid with healthy honeybees, the time dependence is approximately t2 , indicating that not only is the exposure cumulative, but also that there are delayed toxic effects.

Queen bees can live for several years.  Queen bees also need to consume large amounts of food in order to churn out the thousands of eggs they lay every day.  This make queen bees especially susceptible to such a toxin. Queen failure was one of the precursors to colony mortality found by vanEngelsdorp et al. (2013).  Queen failure, even if the bees succeed in raising a new one, will leave the colony without a fresh supply of young bees.  A colony with pesticide stress may be relying on young bees to make up for those that disappear before their time.

I only looked at studies that addressed bee mortality.  Bees affected by pesticide may not immediately die, but they may be practically useless to the colony, or may be unable to forage or navigate, and hence become lost and perish outside the hive.  Quantifying behavioral effects is more difficult than counting dead bees, but one might expect that the time-to-effect scaling would be similar to the mortality data.

Bibliography

Alaux, C., Brunet, J.-L., Dussaubat, C., Mondet, F., Tchamitchan, S., Cousin, M., Brillard, J., Baldy, A., Belzunces, L. P. and Le Conte, Y. (2010), Interactions between Nosema microspores and a neonicotinoid weaken honeybees (Apis mellifera). Environmental Microbiology, 12: 774–782. doi: 10.1111/j.1462-2920.2009.02123.x

Aufauvre, J., D.G. Biron, et al. (2012). Parasite-insecticide interactions: a case study of Nosema ceranae and fipronil synergy on honeybee. Scientific Reports 2: 326. doi:10.1038/srep00326

Cornman RS, Tarpy DR, Chen Y, Jeffreys L, Lopez D, et al. (2012) Pathogen Webs in Collapsing Honey Bee Colonies. PLoS ONE 7(8): e43562. doi:10.1371/journal.pone.0043562

Cresswell, J.E. (2011). A meta-analysis of experiments testing the effects of a neonicotinoid insecticide (imidacloprid) on honey bees. Ecotoxicology,20(1), 149-157.

DEFRA – Department for Environment, Food and Rural Affairs (20o7): Assessment of the risk posed to honeybees by systemic pesticides. March 2007.

vanEngelsdorp D,  Tarpy DR, Lengerich EJ, Pettis JS, Idiopathic brood disease syndrome and queen events as precursors of colony mortality in migratory beekeeping operations in the eastern United States.  Preventive Veterinary Medicine, 108,  2–3, February 2013, Pages 225–233.

FERA – Food and Environment Research Agency, Neonicotinoid Pesticides and Bees,Report to Syngenta Ltd.
January 2013.

New York Times, March 29, 2013. Mystery Malady Kills More Bees, Heightening Worry on Farms

Sánchez-Bayo, F.,2009. From simple toxicological models to prediction of toxic
effects in time. Ecotoxicology 18,343–354.

Suchail, S.,Guez,D.,Belzunces, (2001),  Discrepancy between acute and chronic toxicity induced by imidacloprid and its metabolites in Apis mellifera. Environ.Toxicol.Chem. 20,2482–2486.

Suchail, S., Debrauwer, L. and Belzunces, L. P. (2004), Metabolism of imidacloprid in Apis mellifera. Pest. Manag. Sci., 60: 291–296. doi: 10.1002/ps.772

Tennekes HA, Sánchez-Bayo F (2011) Time-Dependent Toxicity of Neonicotinoids and Other Toxicants: Implications for a New Approach to Risk Assessment. J Environment Analytic Toxicol S4:001. doi:10.4172/2161-0525.S4-001

The French Exerpience

April 26, 2013

It all started with bees in the sunflowers in France. It hasn’t let up. These videos tell the depressing and frustrating story of the French experience.

Part One:

Part Two

Part Three

Part Four

I’m getting rid of Imidacloprid – Avoiding the Worst Neonicotinoid Insecticides

March 27, 2013

I’m often asked which products are OK and which should be avoided.  Hence the mnemonic in the title to help you remember I’m getting rid of Imidacloprid.  Say it three times out loud, and when you read the labels at the garden store you will remember:  I’m getting rid of Imidacloprid.

When it comes to insecticides, first ask yourself , do you really need them?  Rather than automatically reaching for a spray bottle, first take a close look at your foe.  Do you know what it is, its life cycle?  What will happen if you do nothing?  Are there any natural predators around?  Open your eyes to the fascinating world of insects and their daily dramas before killing them all.

Attentive gardeners are always on the lookout for the pests they have come to know.  I expect cabbage caterpillars to appear as soon as I see the pretty white butterflies flitting about.  So I watch the plants for any sign of the worms and many times I notice predatory wasps patrolling with me.  I don’t get all of the worms by hand picking; there are always some left for the wasps.  Between us, we don’t need anything else to keep the worms off the broccoli.  Hand picking works for many garden pests.

Healthy plants are more resistant to insect pest.  Good growing conditions, water and organic fertilizer are your first choices to solve problems.  A good resource when you have problem is NCAP’s solution tool box.  Occasionally you may be driven to need something more.  So lets look at the good, the bad, and the ugly, when it comes to garden chemicals.

The Good: Soaps and Oils

GoodThe least toxic chemicals are often soap or fat/oil based emulsions that disrupt the pest with little environmental impact.  Safer Brand and EcoSmart products are generally a good choice for chemical products that have low toxicity and are usually derived from organic ingredients.  The major pesticide brands like Ortho and Bayer also have lines of less toxic chemicals but I would suggest patronizing brands that generally avoid the worst chemicals in all of their products.  Read the labels!

The Bad: Neonicotinoid Pesticides

There are plenty of bad chemicals.  I’m mostly concerned about the insidious,  highly toxic neonicotinoid insecticides because they are long-lasting in the environment and sub-lethal amounts of toxin will accumulate and cause harm in bees and other beneficial insects.  The list of products that contain neonicotinoid insecticides is a long one.  Common on this list are foliar sprays for direct control of insect pests. Bad
Ortho brand sprays usually contain acetamiprid, a neonicotinoid that is less toxic and more quickly degrades than imidacloprid. Bayer foliar sprays contain imidacloprid.  The extended length of time the chemicals continue to kill insects can clue you in on how much active ingredient is being spread about and their relative environmental impact.  The Bayer Complete Insect Killer has a lot of active ingredient and really belongs with the ugly product below.

The Ugly: Mindless-Use, Soil-Contaminating, Neonicotinoid Pesticides

These are the real problems.  Insecticides that are applied in the soil need to have more active ingredient in order that enough is taken up by the plant to be effective.  This means that much more is still left in the soil where it can contaminate non-target plants for many years and eventually move into the ground water.

Ugly

Tree and shrub product use large amounts of chemical. Many flowering shrubs are prime bee forage, make an attractive and deadly combination.  The soil around treated trees will grow toxic flowers for years.  The “all-in-one” and “protect & feed” products contain fertilizer as well as imidacloprid.  This leads to mindless needless insecticide use and soil contamination.  The Bayer All-in-One Rose and Flower Care also contains clothianidin, another deadly neonicotinoid, in addition to imidacloprid.  Please do not use these chemicals, for the sake of the bees and the entire invertebrate eco-system.

Remember, I’m getting rid of imidacloprid!

The Case Against Imidacloprid

March 3, 2013

Ever since French beekeepers saw their bees dying as they collected pollen from treated sunflowers back in 1996, beekeepers have been concerned that their bees are being harmed the highly toxic neonicotinoid insecticides, with imidacloprid most widely used. The use of this class of insecticide has grown steadily ever since. Bee losses have become chronic as well. However, unlike the first case in France where bees were literally falling dead while gathering pollen, the widespread colony losses today are less explainable, often associated with outbreaks of a variety of diseases, and with very high winter colony mortality. So why blame the insecticides?

To see why the bees are dying, and why these pesticides are still being sold, we must examine the toxicology of the neonicotinoid chemicals as well as the history and science of pesticide regulation.  The toxic nature of a chemical is characterized by its “LD50” level.  This is the amount of chemical that will kill half of the test organisms in short order.  For many traditional pesticides (organophosphates), the LD50 level provides an adequate overall characterization of toxic effect.  These pesticides tend to be short-lived and generally do not bio-accumulate in the target organism.  If the dose doesn’t kill the organism, the toxic compound will be metabolized and excreted.  Since the organophospate pesticides — which for many years made up the majority of pesticides sold — could be characterized easily with the single LD50 number, the culture of pesticide regulation largely accepts the acute LD50 as determinative for all toxic effects.

The acute LD50 characterization works poorly for substances that bio-accumulate and/or have a relatively long time-to-effect characteristic.  Substances that fall into this category are heavy metals that are known to accumulate in certain tissues, and some carcinogens where an initial single exposure can give rise to cancers much later in the life of the organism.   Neonicotinoid insecticides also fit into this category.  These insecticide molecules bond strongly and irreversibly at nicotine receptor sites in the central nervous system.  There is also evidence of delayed time-to-effect of several days for exposures below the acute LD50  [Suchail et. al.(2001)].

Toxicologists attempt to model the time-dependent effects of chemicals at various dose levels [Tennekes, (2010)].  One of the simplest empirical models assumes the dose/effect relationship can be characterized by a simple “power law”  where the effect is proportional to the dose multiplied by the time-of-exposure raised to a power, b.

Effect = Dose x Timeb

Instead of a single number, now we have two numbers to characterize toxicity, the dose and the time exponent.  When a power law is plotted with logarithmic scales, one gets a straight line with slope equal to the exponent, b, and intercept equal to the Dose.  The time-independent, acute LD50 model is the special case when b=0.  For a simple bio-accumulation model, one would expect linearity in time with b=1.  Time-to-effect mechanisms require b>0.  Combinations of effects for a given organism and chemical will result in a Dose vs Effect curve with characteristic slope that includes all of the time-dependent mechanisms embedded in the value of the exponent.

Imidacloprid Toxicity

The plot above shows some published data on imidacloprid toxicity on a log-log graph.  Data for two species of small aquatic crustaceans, Daphnia magna (red squares) and Cypridopsis vidua (blue diamonds) illustrates the large range of toxicity difference between organisms, and also the large range of applicability of the model, spanning more than three orders of magnitude in concentration. [Sánchez-Bayo et. al. 2009]  Honeybees (green triangles) also have high toxicity over a wide range of concentrations [Suchail et. al.(2001)].

The best-fit power law curves are shown in the plot.  In all cases, the fit parameter, R2, is greater than 0.85. The time exponent for Daphnia, 1.3, is barely more than linear, where as for Cypridopsis and honeybees the exponent is close to 5. This means that there are strong time-dependent delayed effects from the chemical for the Cypriopsis and honeybees. The time5 dependence of the toxicity of imidacloprid for honeybees is the big problem.  Very low levels of exposure, with sufficient time, will be lethal. The power law model suggests that we should extend the time of exposure to the lifetime of the organism in order to determine the minimum dose that will have no effect. Honeybees, including the larval stage, live ~50 days in the summer and ~100 days for wintering bees. Extrapolating the green dashed line trying to reach 50 to 100 days would require reducing continuous exposure to less than 0.0001 parts per billion (ppb). This minuscule exposure level is far below the detectable limits of present technology (~1 ppb).  What we can detect are residual levels in nectar and pollen on treated plants commonly in the 1 – 10 ppb range; even these small levels are more than 10000 times the level that the power law model suggests would cause no harm to adult bees.  Looked at another way, if one bee in 10,000 returns to the colony with pollen gather from a treated plant, that would be enough toxin to begin to cause damage to the colony.

Collecting toxicity data about bees is a complex process, involving multiple trials, caged bees to limit their activity to the test sample, etc.  Aquatic crustaceans provide an easier test subject where dosage can be controlled by dilution of the water they live in.  The fact that the crustaceans conform to the power law model confirms that imidacloprid is bio-accumulative.  The same finding by Suchail et.al. for bees should not be surprising, given that both organisms have central nervous systems with nicotine receptors.

What about mammals and humans?  Very little time-dependent information is available.  There are a couple of data points on the plot above for mice.  One point was the LD50 for short time exposure and the other the threshold for immune system compromise exposed for 28 days. The data for mammals is just not available yet, but even much more modest sensitivity to the chemical could present problems for long-lived species such as humans.  There is also fear that these biologically persistent chemicals could be fueling world-wide wild life declines in many species [Mason, R. et. al. 2012].

Our regulators, (EPA) are not adequately considering the time-dependent nature of the lethal effects of the neonicotinoid class of pesticides.  The most toxic and long-lived chemicals, imidacloprid, clothanidin, and thiamethoxam should be removed from the market before more harm is done, as is happening in Europe.  Other insecticides in this class should be subject to further scrutiny as well.

The social nature of bees naturally draws one to a human analogy. Imagine that a toxic chemical is slowly poisoning our brains. (Think lead pipes and the Romans.) Instead of healthy people living into their 70’s, the toxic effects are bringing on Alzheimer’s-like symptoms to folks in their 40’s and 50’s. The younger healthier part of the population has its hands full, providing for themselves and those that no longer support their own livelihood. Everyone is hungry. Now introduce a bad case of the flu, or the plague, and the already weakened population is devastated.  That is what our bees are facing today. The levels of poison are rising as more and more of these pesticides are being used, building up in our soil and in treated plants.  The bees are dying younger, and we are gradually eliminating a host of insects and creatures we don’t even know we are poisoning.

Mason, R., H A Tennekes, F Sánchez-Bayo, P U Epsen (2012) Immune suppression by neonicotinoid insecticides at the root of global wildlife declines. J Environ Immunol Toxicol 1: (in press)

Sánchez-Bayo, F.,2009. From simple toxicological models to prediction of toxic
effects in time. Ecotoxicology 18,343–354.

Suchail, S.,Guez,D.,Belzunces,2001. Discrepancy between acute and chronic toxicity induced by imidacloprid and its metabolites in Apis mellifera. Environ.Toxicol.Chem. 20,2482–2486.

Tennekes, H, A. The significance of the Druckrey-Kupfmuller equation for the risk assessment — the toxciity of neonicotinoid insecticides to arthropods is reinforced by exposure time.  Toxicology. 2010 Sep 30;276(1):1-4

Stores Stop Selling Bee-Killing Pesticides

February 9, 2013

Last week three major home store chains in the UK took insecticides with troublesome neonicotinoid systemics off their shelves.  The chains, Wicks, B&Q, and HomeBase no longer have insecticides containing clothianidin, imidacloprid and thiamethoxam, the three neonicotinoids deemed most toxic and problematic to honeybees in a recent announcement from the European Food Safety Authority (EFSA).  The EFSA recommends, among other things,  that for the three most toxic neonics, “only uses on crops not attractive to honey bees were considered acceptable.”

The voluntary ban by the major store chains is the latest development in the deliberative effort going on in Europe concerning bee losses and systemic insecticides.  The body of evidence for the problems with neonicotinoid insecticides is growing larger.  In December 2012, the European Parliament issued a report, Existing Scientific Evidence of the Effects of Neonicotinoid Pesticides on Bees, as they struggle to decide what to do about increasing bee losses in Europe.  The authors recommend banning or severely restricting use of the worst offenders.  This is on the heels of a very complete, 265 page report issued by the EFSA in May 2012, Scientific Opinion on the science behind the development of a risk assessment of Plant Protection Products on bees (Apis mellifera, Bombus spp. and solitary bees) which goes into detail about hazards of the neonics.

The process in Europe is deliberative.  The consensus-building  necessary for new Europe-wide regulations began with the compilation of all the scientific evidence, pro and con, concerning the safety of these chemicals.  The scientific reports document the known problems and also raise the issue that there are no adequate studies of long-term sub-lethal effects of these very toxic chemicals that focus on whole-colony dynamics with honey bees or consider other native species.   The next step in the process would be for the EU to write language to actually institute a Europe-wide ban the use of the insecticides where they are harmful to bees.  This is likely to happen in the coming months.

In the meantime, reaction to the recent announcement has been mixed.  Bayer and other manufacturers of the chemicals have denounced the recommendation, predicting dire consequences to the corn crop if the chemicals are banned.  However, in the UK, the home center stores have voluntarily removed products containing the troubling insecticides from their shelves.

In the US, the Environmental Protection Agency (EPA) has been slower to act.  Despite the concerns of beekeepers and environmentalists that resulted in EPA consideration of a petition in 2012, the agency refused to make any changes in the regulatory status of clothianidin.  The threat in the US is not only with chemicals marketed to industrial agriculture.  Increasingly, Bayer is including neonics in their home garden insecticides aimed at individual home owners and gardeners.  This is especially troubling in our communities where urban beekeeping must coexist with urban gardeners.

Colony losses continue to mount.  Early reports for colony health coming through this winter are discouraging.  It is likely that for the first time there will not be sufficient bees available in the US for the California almond pollination event.  Beekeepers my have difficulty finding package bees this spring, as demand to replace dead colonies exceeds the capabilities of the southern producers.

In our community, the Oregon Sustainable Beekeepers have begun circulating a letter requesting local garden centers to stop selling neonicotinoid insecticides.  Although our EPA may not be protecting us from these chemicals, we think that especially with the evidence and recommendations coming from Europe, there is very good reason to get these chemicals out of our communities.  Local activism is our only choice.

Insecticide display at a local garden center.  Red cross outs contain imdocloprid; yellow

Insecticide display at a local garden center. Red cross-outs contain imidacloprid; yellow acetamiprid.

Our group is small and we need assistance.  Please become informed on this issue.  Read some of the European reports linked above.  Then print out our letter, linked below, and go to your favorite garden store and ask them to commit to removing the bee-killing toxics from our community.  Go for it!

Here is our letter:  Request to stop selling neonicotinoids

Excellent new Graham White article posted on Tom’s Corner

January 27, 2013

https://docs.google.com/file/d/0B7FCgF0BwlDGN25iTHoxdlhabms/edit?pli=1

Graham sure drives home the ecocide issue- but what are we going to do about it?
